Factory Lead Time

9 Weeks

Mount

PCB, Surface Mount, Through Hole

Mounting Type

Surface Mount

Body Material

Brass

Center Contact Plating

Gold

Center Contact Material

Beryllium Copper

Contact Materials

Copper

Frequency(Max)

12GHz

Insulation Materials

LIQUID CRYSTAL POLYMER/POLYETHERETHERKETONE

Operating Temperature

-65°C~165°C

Packaging

Bulk

Published

2001

JESD-609 Code

e4

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

ECCN Code

EAR99

Connector Type

Jack, Male Pin

Gender

Female

Additional Feature

VSWR IS MAX AT 20GHZ

Fastening Type

Snap-On

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Filter Feature

NO

Option

GENERAL PURPOSE

Total Number of Contacts

1

Orientation

Straight

Frequency

40GHz

Reliability

COMMERCIAL

Body Depth

0.236 inch

Polarity

Standard

Body/Shell Style

PLUG

Dielectric Withstanding Voltage

700VAC V

Impedance

50Ohm

Wire/Cable Type

Coaxial

Connector Style

SMP

Number of Ports

1

Insertion Force-Max

44.48 N

Withdrawl Force-Min

8.896 N

Mating Cycles

500

Contact Termination

Solder

VSWR

1.2

Features

Limited Detent

REACH SVHC

Unknown

Radiation Hardening

No

RoHS Status

RoHS Compliant
